Standard 6 Hook Patio Door Lock

Web Code: 11108 | Product Code: DPL1500

The ERA Standard Patio Door Locking System is a six point multi-point lock suitable for PVCu sliding patio doors.

Read Full Description | Read Further Information

Features

  • 1500mm Lock
  • Anti slam pin on gearbox prevents misalignment of the lock until the door is closed correctly
  • 18mm backset and overall lock case depth of 33mm for ease of fabrication and minimal prep
  • Bi-directional throw of hooks for anti jemmying security, strength and durability
  • Gearbox compatible with a standard Euro Cylinder
  • Datum line on the lock ensures accurate alignment with the keep during fabrication
*Required field
eg; D210

Minimum qty: 5

Are you a homeowner? Visit our dedicated site here

In Stock

0 x this product has been added to your basket. Product availability may affect the quantity added to your basket
Checkout Now

This product could not be added to your basket.

This product could not be added to your basket as the quantity is not a multiple of the minimum order quantity.

This product could not be added to your basket as a keycode is required.

Further information

Technical Spec
Corrosion Meets the requirements of BS EN 1670 Grade 4 Corrosion Resistance (240 hours)
Operation Endurance tested in excess of 100,000 cycles
Product Weight 1.12kg
Product Measurements (mm) 1500mm x 15.8mm x 33mm

Full Description

The ERA Standard Patio Door Locking System is a six point multi-point lock for PVCu sliding patio doors. The bi-directional throw of steel hooks resists jemmying, giving the lock strength and durability. The anti-slam pin on the gearbox prevents misalignment of the lock until the door is closed correctly and a central anti-lift pin ensures location into the keep before locking and protects against jemmying. Fitted with a datum line on the lock to ensure accurate alignment with the keep during fabrication.

The full width non handed continuous keep is manufactured from extruded heat treated Aluminium and anodised silver for aesthetics. It is fully adjustable via the sliding black packer that allows for +/-2mm misalignment of keep and/or door drop. The lock has an 18mm backset with an overall lock case depth of 33mm for ease of fabrication and minimal preparation to the profile. Compatible with a standard Euro Cylinder, the lock is suitable for handles with a 7mm spindle and 92mm centre, ideally for use with the Fab&Fix Pembroke patio handle.

Each locking cluster has a 4 screw fixing to secure the profile and keeps are available to suits most major PVCu profiles.
